F-22 Raptor
Specifications
(F-22 Raptor) General
characteristics * Crew: 1 * Length: 62 ft 1 in (18.90 m) * Wingspan: 44 ft 6 in (13.56 m) *
Height: 16 ft 8 in (5.08 m) * Wing area: 840 ft² (78.04 m²) * Airfoil: NACA 64A?05.92 root, NACA
64A?04.29 tip * Empty weight: 43,430 lb (19,700
kg[1][83]) * Loaded weight: 64,460 lb (29,300 kg[84]) * Max takeoff weight: 83,500 lb (38,000 kg) * Powerplant: 2× Pratt & Whitney
F119-PW-100 Pitch Thrust vectoring turbofans, 35,000+ lb (156+kN) each Performance * Maximum speed: o At altitude: Mach 2.25 (1,600+ mph,
2,414 km/h) o Supercruise: Mach 1.82 (1,220 mph,
1,963 km/h) * Range: 1,600 nmi (1,840 mi, 2,960 km)
with 2 external fuel tanks * Combat radius: 410 nmi (471 mi, 759 km) * Ferry range: 2,000 mi (1,738 nmi, 3,219
km) * Service ceiling 65,000 ft (19,812 m) * Wing loading: 66 lb/ft² (322 kg/m²) * Thrust/weight: o With full internal fuel: 1.09
(18,000 Pounds) o With 50% internal fuel: 1.26 (9,000
Pounds) * Maximum g-load: -3.0/+9.0 g Units:
94th Fighter Squadron  |
Armament * Guns: 1× 20 mm (0.787 in) M61A2 Vulcan
gatling gun in starboard wing root, 480 rounds * Air to air loadout: o 6× AIM-120 AMRAAM o 2× AIM-9 Sidewinder * Air to ground loadout: o 2× AIM-120 AMRAAM and o 2× AIM-9 Sidewinder and one of the
following: + 2× 1,000 lb (450 kg) JDAM or + 2× Wind Corrected Munitions
Dispensers (WCMDs) or + 8× 250 lb (110 kg) GBU-39
Small Diameter Bombs * Additionally, four external hardpoints
can be fitted to carry weapons or fuel tanks, each with a capacity of about 5,000 lb
(2268 kg). Avionics * RWR (Radar warning receiver): 250 nmi
(463 km) or more * Radar: 125-150 miles (200-240 km) against
1 m² targets (estimated range) |
