B-2 Spirit
Specifications
(B-2A) General
characteristics * Crew: 2 * Length: 69 ft (21 m) * Wingspan: 172 ft (52.4 m) * Height: 17 ft (5.2 m) * Wing area: 5,000 ft² (460 m²) * Empty weight: 158,000 lb (71.7 t) * Loaded weight: 336,500 lb (152.6 t) * Max takeoff weight: 376,000 lb (171.0 t) *
Powerplant: 4× General Electric F118-GE-100 turbofans, 17,300 lbf (77 kN) each Performance * Maximum speed: 410 knots (760 km/h, 470
mph) * Range: 5,600 nm (10,400 km, 6,400 mi) * Service ceiling 50,000 ft (15,000 m) * Wing loading: 67.3 lb/ft² (329 kg/m²) * Thrust/weight: 0.205 Units:
13th Bomb Squadron  |
Armament * 2 internal bays for 50,000 lb (22,700 kg)
of ordnance. o 80× 500 lb class bombs (Mk-82)
mounted on Bomb Rack Assembly (BRA) o 36× 750 lb CBU class bombs on BRA o 16× 2000 lb class weapons (Mk-84,
JDAM-84, JDAM-102) mounted on Rotary Launcher Assembly (RLA) o 16× B61 or B83 nuclear weapons on
RLA |
